DIN Rail Mount Weighing Controller

Name: Load Controller
Brand: ADI ARTECH TRANSDUCERS PVT. LTD.

10500.0 INR/Number

Get a Price/Quote

Product Details:

Usage Filling & Bagging Systems Batching Industry Production Line Quality Control (GO / NO-GO) PLC & HMI Integration Remote Weight Display
Display Digital LED display
Voltage 220-240V AC Volt (v)
Power Up to 10 kW Watt (w)
Product Type Load Controller
Power Rating SMPS
Material ABS, flame-retardant plastic
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

DIN Rail Mount Weighing Controller Price And Quantity

Price 10500.0 INR/Number
Minimum Order Quantity 1 Number

Protection Overload, short-circuit, and surge
Connection Screw terminals
Frequency 50/60 Hz
Operating Humidity 10% to 90% RH, non-condensing
Ambient Temperature -10C to 55C
Relay Output Electromechanical, 1 NO + 1 NC contacts
Enclosure Rating IP20
Control Method Automatic ON/OFF based on load threshold
Response Time <50 ms
Installation Type Surface mounting

DIN Rail Mount Weighing Controller Product Specifications

Product Type Load Controller
Design Wall-mount compact design
Dimension (L*W*H) 120mm x 90mm x 55mm Millimeter (mm)
Usage & Applications Industrial weight monitoring and process control
Phase Single Phase
Power Source AC mains
Warranty 1 Year
Power Rating SMPS
Features DIN Rail Mount, 6 Indication LEDs, Peak / Valley / Max / Min Display, Weight Linearization (Up to 10 Points) Modbus Communication , Ethernet (Optional), External Tare Option , Process Automation Ready
Frequency 50 60 Hz Hertz (HZ)
Usage Filling & Bagging Systems Batching Industry Production Line Quality Control (GO / NO-GO) PLC & HMI Integration Remote Weight Display
Material ABS, flame-retardant plastic
Weight 400g Grams (g)
Detector Integrated current transformer
Cable Type NOt Applicab;e
Display Digital LED display
Accuracy FA %
Charging Time No charging required (AC powered) Minutes
Voltage 220-240V AC Volt (v)
Display Type 6 Digit Red 7-Segment LED Display
Operating Temperature Not Applicable Celsius (oC)
Rated Voltage Not Applicable Volt (V)
Conductor Supports up to 8 load cells of 350 each
Power Up to 10 kW Watt (w)

Protection Overload, short-circuit, and surge
Connection Screw terminals
Frequency 50/60 Hz
Operating Humidity 10% to 90% RH, non-condensing
Ambient Temperature -10C to 55C
Relay Output Electromechanical, 1 NO + 1 NC contacts
Enclosure Rating IP20
Control Method Automatic ON/OFF based on load threshold
Response Time <50 ms
Installation Type Surface mounting

DIN Rail Mount Weighing Controller Trade Information

FOB Port VADODARA
Payment Terms Cash Advance (CA), Cash in Advance (CID), Cheque
Supply Ability 100 Number Per Month
Delivery Time 1 Week
Sample Available Yes
Main Export Market(s) Asia, Australia, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India

Product Description

The DLC-6DR is a compact, DIN-rail mounted Digital Load Controller and Transmitter designed for industrial weighing and process automation applications. It supports up to 8 load cells (350 each) and features a 6-digit red 7-segment display for clear visibility in industrial environments.

Equipped with a 24-bit high-precision A/D converter, the unit ensures reliable and accurate weight measurement. It offers multiple communication options including RS-485 (Modbus RTU) and optional Ethernet (Modbus TCP/IP), making it easy to integrate with PLCs, HMIs, and SCADA systems.

The controller provides selectable analog outputs (010V, 10V, 420mA, etc.), relay outputs for automation control, and advanced features like peak/valley detection, weight linearization (up to 10 points), and GO/NO-GO logic for quality control applications.

It is ideal for:
