Flat type Tensoin Link

Name: Flat type Tensoin Link
Brand: ADI ARTECH TRANSDUCERS PVT. LTD.

7500.00 - 250000.00 INR/Piece

Get a Price/Quote

Product Details:

Resistance 350 Ohms
Output Analog
Theory Strain Gauge Sensor
Type Flat Type Tension Link
Accuracy 0.05% F.S.
Operating Voltage 10V DC (Excitation)
Output Voltage 2.0 mV/V 0.1 mV/V
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Flat type Tensoin Link Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 7500.00 - 250000.00 INR/Piece

Flat type Tensoin Link Trade Information

Supply Ability 10 Piece Per Week
Delivery Time 1 Week

Product Description

Flat type Tensoin Link

Model	:	20410-FLAT
Capacity	:	0-5Tf to 0-200Tf
Load Direction	:	Tension only
Type	:	Crane Load Cell , In Line Force Sensor , Tension Link Load Cell , Tension Load Cell

Industries

Ship Yards
Weighing
Shipbuilding
Crane Manufacturing

Application

Bollard Pull Test Dynamometer
Bridge Rope Tension Measurement
Cargo Handling in Ship Yards
Lifting Equiptment Load Measurement
Pulling Force Measurement
Rail Road Coupling
Rope Tension Measurement
Tension Force Measurement
Tension Measurement in Railway Catenary , Suspension & Stay Ropes
Tow Bar Connection
Vehicle Pull Test
Winch Pull Force Measurement

Description

Strain gage based load cell model 20410 -FLAT is versatile,compact and rugged.
It is used for tension measurements,crane weighing.
Tension loading is applied through a pair of shackles.
It meets to IP 67 environmental class protection.

Features

0-5Tf to 0-200 Tf capacities are available.
This load cell is compact and light weight for portability.
High alloy tool steel construction is for ruggedness and safety.
Optionally High temperature version for foundry applications can be offered upon request.

Electronic Instrumentation / Software

Compatible Electronic Systems are available optionally-
Stand alone digital display indicator.
Analog signal converter - 0 - 10 VDC or 4 - 20 mA for PLC interface.
Digital signal converter - RS-232 , RS-485 or MODBUS RTU Protocol to interface with computer or other processing equipment.
Data acquisition system and software.
For details,please contact us.

Mounting Hardware

Please contact us for details.

Accurate and Durable Measurement

Experience precise tension measurement with an accuracy of 0.05% F.S. The robust alloy steel construction and nickel plating guarantee stability and a long service life, even when subjected to tough industrial environments. Through-hole mounting delivers easy and secure installation for various crane and lifting applications.

Versatile Industrial Applications

Suited for cranes, lifting systems, and force monitoring, this Flat Type Tension Link adapts seamlessly to a wide range of industrial uses. The analog output and 5m standard cable facilitate quick integration with most monitoring equipment, ensuring your operations benefit from real-time, reliable readings.

Reliable Operation under Extreme Conditions

Designed to withstand challenging environments, the Tension Link operates smoothly from -20C to +70C, with a storage range extending from -25C to +85C. The IP67 protection rating shields the device from dust and water ingress, making it suitable for both indoor and outdoor applications.

FAQs of Flat type Tensoin Link:

Q: How is the Flat Type Tension Link installed in crane and lifting systems?

A: The Tension Link is mounted using its through-hole design, allowing secure attachment directly to crane hooks or between lifting points. Its 5m standard cable simplifies wiring to monitoring or control equipment.

Q: What are the main benefits of using a Flat Type Tension Link in industrial settings?

A: This tension link provides precise force measurement, enhanced safety with overload protection (up to 200% F.S.), robust corrosion resistance, and adaptability to various heavy-duty applications in both indoor and outdoor environments.

Q: When should the overload limits be considered during operation?

A: Overload limits150% F.S. for safe and 200% F.S. for ultimateshould be monitored to ensure operational safety and to prevent sensor damage. Regularly check load readings and avoid exceeding specified thresholds during lifting or tension measurement tasks.

Q: Where can this Tension Link be used besides crane scales?

A: Apart from crane scales, it is widely applicable in tension measurement, load monitoring, lifting applications, and other industrial processes that require reliable force sensing and measurement.

Q: What process technology does the Tension Link utilize for measurement?

A: The device uses strain gauge sensing technology, which translates mechanical strain into an electrical analog output, ensuring accurate force measurements suitable for precision applications.

Q: How can users ensure optimal performance and longevity of the Tension Link?

A: To maximize lifespan, always operate within the specified temperature and overload limits, utilize appropriate mounting hardware, and periodically inspect for mechanical wear or corrosion on the devices surface.
