Rope Tension Scale Load Cell

Name: Rope Tension Scale Load Cell
Brand: ADI ARTECH TRANSDUCERS PVT. LTD.

7500.00 - 250000.00 INR/Piece

Get a Price/Quote

Product Details:

Resistance 350
Theory Resistance Strain Gauge
Type Rope Tension Scale Load Cell
Accuracy 0.03% F.S.
Operating Voltage 515V DC
Output Voltage 1.02.0 mV/V
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Rope Tension Scale Load Cell Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 7500.00 - 250000.00 INR/Piece

Rope Tension Scale Load Cell Product Specifications

Theory Resistance Strain Gauge
Resistance 350
Type Rope Tension Scale Load Cell
Output Voltage 1.02.0 mV/V
Accuracy 0.03% F.S.
Operating Voltage 515V DC

Rope Tension Scale Load Cell Trade Information

Supply Ability 10 Piece Per Week
Delivery Time 1 Week

Product Description

Rope Tension Load Cell

Model	:	30510
Capacity	:	0-1Tf to 0-50Tf
Load Direction	:	Tension only
Type	:	In Line Force Sensor , Low Profile Shear Beam Load Cell , Rope Tension Load Cell

Industries

Elevator & Lift Manufacturing
Crane Manufacturing
Civil Engineering

Application

Bridge Rope Tension Measurement
Cargo Handling in Ship Yards
Crane Test Dynamo meter
Elevator Load Monitoring
In-Line Force Measurement
Lifting Equipment Load Measurement
Marin Towing
Over Load Limitting
Vehicle Pull Test

Description : This is clamp on type load cell which can be fitted to the existing rope without disturbing the set up.

Features

Compatible Electronic Systems are available optionally-
Stand alone digital display indicator.
Analog signal converter - 0 - 10 VDC or 4 - 20 mA for PLC interface.
Digital signal converter - RS-232 , RS-485 or MOD BUS RTU Protocol to interface with computer or other processing equipment.
Data acquisition system and software.
Please contact us for more details

High-Precision Rope Tension Measurement

Engineered for exceptional accuracy, this Rope Tension Scale Load Cell harnesses resistance strain gauge theory, providing 0.03% F.S. precision. Its design ensures reliability and stability even in demanding environments, making it a preferred choice for industries requiring meticulous tension monitoring in hoisting, lifting, and material handling operations.

Versatile Operation and Compatibility

With an output voltage between 1.02.0 mV/V and compatibility with 515V DC systems, this load cell seamlessly integrates into existing measurement setups. The standard 350 resistance supports consistent operational performance, meeting industry requirements for various tension measurement applications across India.

FAQs of Rope Tension Scale Load Cell:

Q: How does the Rope Tension Scale Load Cell measure tension accurately?

A: This load cell utilizes the resistance strain gauge method to precisely detect variations in rope tension, resulting in highly accurate outputs with an error margin of only 0.03% of the full scale.

Q: What are the typical uses for this Rope Tension Scale Load Cell?

A: It is commonly employed in cranes, elevators, cable cars, and other industrial applications where precise rope tension is critical for safety and operational efficiency.

Q: When should I recalibrate my Rope Tension Scale Load Cell?

A: Recalibration is recommended annually or after any significant physical impact, ensuring that the device maintains its factory-set accuracy over time.

Q: Where can I purchase this Rope Tension Scale Load Cell in India?

A: You can obtain it from authorized dealers, distributors, exporters, manufacturers, suppliers, traders, and wholesalers throughout India, ensuring easy local availability and support.

Q: What is the benefit of using a load cell with 0.03% F.S. accuracy?

A: The high accuracy minimizes measurement errors, providing reliable data essential for critical operations where safety and efficiency are paramount.

Q: How is the load cell installed in a rope system?

A: The load cell is typically mounted inline with the rope, allowing strain forces to be transmitted directly through the sensor for real-time tension monitoring.
