Side Mounted Bending Beam Load Cell

The ADI ARTECH Model 60910 is a side-mounted beam load cell specifically designed for soil testing machines and industrial weighing applications. Manufactured from high-strength tool steel with an electroless nickel-plated finish, it offers excellent corrosion resistance and long-term durability. The load cell utilizes strain gauge technology with full temperature compensation from 0C to 50C, ensuring stable and reliable performance under varying environmental conditions. With IP65 protection, it is suitable for demanding industrial environments. The Model 60910 is widely used in hopper weighing, tank weighing, forklift load measurement, and material handling systems. Capacities ranging from 50 kgf to 500 kgf are available, with custom capacities offered upon request.

FAQs

1. What is the Model 60910 load cell used for?

The Model 60910 is used for soil testing machines, hopper weighing, tank weighing, forklift load measurement, and material handling applications.

2. What type of load cell is the Model 60910?

It is a side-mounted beam load cell based on strain gauge technology.

3. What capacity range is available?

Standard capacities range from 50 kgf to 500 kgf, with additional custom capacities available on request.

4. What material is used in its construction?

The standard model is manufactured from tool steel with an electroless nickel-plated finish. An optional stainless steel version is also available.

5. Is the load cell suitable for harsh industrial environments?

Yes. It features IP65 environmental protection and corrosion-resistant construction, making it suitable for industrial applications.

6. What is the recommended excitation voltage?

The load cell operates with a nominal excitation voltage of 10 VDC and can withstand up to 15 VDC maximum.

7. What is the operating temperature range?

The load cell is temperature compensated for operation between 0C and 50C.

8. Can the load cell withstand overload conditions?

Yes. It can safely handle up to 150% of its rated capacity and withstand ultimate overloads up to 250% of rated capacity.

9. Is the load cell easy to install?

Yes. The compact side-mounted design allows for straightforward installation in various weighing systems.

10. What are the main advantages of the Model 60910?

Its rugged construction, corrosion resistance, overload protection, temperature compensation, and versatility make it a reliable solution for industrial weighing and testing applications.
